The radio station was established as a successor to the R-107M radio station, which has failed completely during the fighting in Afghanistan. She was too heavy and "power-hungry" as the terms of activities in the difficult mountain terrain, away from their own logistics.
You can see it on multiple frames of Russian war movie "The ninth pilgrimage". The furnishings of the Polish Army went in a few copies in the late '80s.
Frequency range | 30 - 75,999 MHz |
Modulation | frequency modulation (FM) tone telegraphy |
Frequency change | step tuning at 1 kHz |
Work | without seeking and tunable ensured by the frequency synthesis for systems using quartz frequency standard |
Intermediate frequency | 11,5 MHz and 1,5 MHz |
Output power | 5 - 10 W (transmitter) |
Sensitivity | no worse than 1 μV |
Frequency deviation | 5 kHz |
Control | local and remote via the telephone line and the field telephone |
Power | from the joining NiCd batteries 12 V / 8 Ah or special car adapter |
Work time | approx. 8 hours with a time of receipt to transmit 5:1 (on one set of batteries) |
Temperature range | -50 to + 50 °C |
